The 2M Series of cartridges from Ortofon have been designed for precise and accurate retrieval of the information in the record groove. Indeed, it is Ortofon's lasting philosophy to only ever play the recorded sound, without colouration. The pre-existing range of 2M cartridges have rapidly been established as a reference point for all good moving magnet cartridges. From the introductory Red, through to the high-end Black; 2M is now a go-to name in moving magnet technology. 2012 sees Ortofon open up new markets within the same design principle of 2M. The 2M 78 and 2M Mono offer users of older, rare vinyl a higher-quality playback medium than had previously been available.

The 2M 78 features an improved True Mono engine, which provides a high level of sonic accuracy, as well as expertly cut Spherical diamond that is perfect for playback of 78 rpm records (which require a larger stylus profile).

2M Verso
The 2M series of cartridges are now also available in a special version, suited for bottom-mount tonearms. The 2M Verso are available to special order in the UK. If you'd like to order one, please call our offices on 01235 511 166 to find out more.

Key Features:

Optimised sound reproduction and high level of sonic accuracy
Spherical diamond that is perfect for playback of 78 rpm shellac records, which require a larger stylus profile
Uses a strapped output to deliver the same output signal from both sets of pole pins
Supplied with 2 different sets of screws (M2.5 x 5 & M2.5 x 7)
Stylus brush included
Also available with integrated headshell or verso version

Awards

Hi-Fi World, April 2013

Reviewed By:	Tony Bolton
Score:	5/5 Globes

Comments of Note:
"A thoroughly impressive cartridge"
"able to extract a wealth of detail from the record grooves and relay it in an inherenty musical and enjoyable manner."
"This is a very effective and affordable solution for most 78rpm replay needs. I will certainly be using one for the foreseeable future."
"Detailed sound, low surface noise and fast and punchy rhythms"

Specs

Output Voltage (at 1kHz	5cm/sec): 4mV
Frequency Range (at -3dB): 20Hz - 22kHz
Frequency Response 20Hz - 20kHz: +3 / -1dB
Tracking Ability at 315Hz: Typically 70μm
Compliance	Dynamic	Lateral: 18μm / mN
Stylus Type: Spherical
Stylus Tip Radius R: 65μm
Tracking Force Range: 1.6 - 2.0g (16 - 20mN)
Recommended Tracking Force: 1.8g (18mN)
Tracking Angle: 20º
Internal Impedance / DC Resistance: 700Ω
Internal Inductance: 300mH
Recommended Load Resistance: 47kΩ
Recommended Load Capacitance: 150 - 300pF
Cartridge Colour Body / Stylus: Black / Grey
Cartridge Weight: 7.2g
Replacement Stylus Unit: Stylus 2M 78
Accessories: Stylus Brush
Screwdriver

£99-£198

Price
