Fezz Equinox Vacuum Tube DAC
Equinox is the worldâs only Lampizator licensed vacuum tube D/A converter designed by Ćukasz Fikus. It is also the cheapest on a market D/A converter with the Lampizator logo. The unit is based on PCM1794 chipsets and 12au7 vacuum tube. Fezz/Toroidy engineers designed a dedicated, highest quality Supreme class toroidal power transformer for Equinoxâs power supply. Device is equipped with 2 Toslink, 1 coaxial and 1 USB digital signal inputs. Thanks to the easily accessible tube, located under the sliding glass on the top panel, units offers the opportunity to create and adjust sound tone according to your own preferences by replacing the tube without any hustle.Specs
| Tube Type | 1x ECC82/12AU7 |
| Circuit type: | Push-pull AB1 Class |
|
Digital inputs:
|
USB type B, 2x S/PDIF, Coaxial |
|
Output:
|
1x RCA |
|
Operation amplifier:
|
Burr Brown PCM 1794 |
| Harmonic distortions THD: | < 0,05% |
|
S/PDIF Receiver:
|
Asahi Kasei AKM4118 |
| Power consumption: | 9 W |
| AC fuse: | 3,15A T |
| Net weight: | 8 kg |
|
Dimensions:
|
355x380x95 mm |
Original: $3,855.43
-65%$3,855.43
$1,349.40Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Equinox is the worldâs only Lampizator licensed vacuum tube D/A converter designed by Ćukasz Fikus. It is also the cheapest on a market D/A converter with the Lampizator logo. The unit is based on PCM1794 chipsets and 12au7 vacuum tube. Fezz/Toroidy engineers designed a dedicated, highest quality Supreme class toroidal power transformer for Equinoxâs power supply. Device is equipped with 2 Toslink, 1 coaxial and 1 USB digital signal inputs. Thanks to the easily accessible tube, located under the sliding glass on the top panel, units offers the opportunity to create and adjust sound tone according to your own preferences by replacing the tube without any hustle.Specs
| Tube Type | 1x ECC82/12AU7 |
| Circuit type: | Push-pull AB1 Class |
|
Digital inputs:
|
USB type B, 2x S/PDIF, Coaxial |
|
Output:
|
1x RCA |
|
Operation amplifier:
|
Burr Brown PCM 1794 |
| Harmonic distortions THD: | < 0,05% |
|
S/PDIF Receiver:
|
Asahi Kasei AKM4118 |
| Power consumption: | 9 W |
| AC fuse: | 3,15A T |
| Net weight: | 8 kg |
|
Dimensions:
|
355x380x95 mm |
